Introducing zchunk

Introducing zchunk, a new file format that’s highly delta-able (is that even a word?), while still maintaining good compression. This format has been heavily influenced by both zsync and casync, but attempts to address the weaknesses (for at least some use-case) in both formats. I’ll cover the background behind this in a later post.

Like casync and zsync, zchunk works by dividing a file into independently compressed “chunks”. Using only standard web protocols, the zchunk utility zckdl downloads any new chunks for your file while re-using any duplicate chunks from a specified file on your filesystem.

Zchunk is a completely new compression format, and it uses a new extension, .zck. By default, it uses zstd internally, but, because it compresses each chunk separately, a zchunk file cannot be decompressed using the zstd utilities. A zchunk file can be decompressed using the unzck utility and compressed using the zck utility.

Zchunk also supports the use of a common dictionary to help increase compression. Since chunks may be quite small, but have repeated data, you can use a zstd dictionary to encode the most common data. The dictionary must be the same for every version of your file, otherwise the chunks won’t match. For our test case, Fedora’s update metadata, using a dictionary reduces the size of the file by almost 40%.

So what’s the final damage? In testing, a zchunk file with an average chunk size of a few kilobytes and a 100KB dictionary ends up roughly 23% larger than a zstd file using the same compression level, but almost 10% smaller than the equivalent gzip file. Obviously, results will vary, based on chunk size, but zchunk generally beats gzip in size while providing efficient deltas via both rsync and standard http.

The zchunk file format should be considered fixed in that any further changes will be backwards-compatible. The API for creating and decompressing a .zck file can be considered essentially finished, while the API for downloading a .zck file still needs some work.

Future features include embedded signatures, separate streams, and proper utilities.

zchunk-0.4.0 is available for download, and, if you’re running Fedora or RHEL, there’s a COPR that also includes zchunk-enabled createrepo_c (Don’t get too excited, as there’s no code yet in dnf/librepo to download the .zck metadata).

Development is currently on GitHub.

Updated 05/03/2018 to point to new repository location


Comments

Hedayat
Saturday, May 5, 2018

That’s great :) I hope it really happens to DNF, although 40% is still large, it is certainly much much better than now!

Thanks a lot

Alexey Tourbin
Tuesday, Jul 3, 2018

Do you group packages by %{SourceRPM} and combine them into a single chunk?

Jonathan Dieter
Wednesday, Jul 4, 2018

Alexey, we check whether the previous package is from the same source rpm, and, if so, combine them into a single chunk. We aren’t currently changing the package order, though that may change.
