I bought a PinePhone a couple of months ago, mainly for the opportunity to play with it and see what it could do. Since I work for a company that does voice call quality testing, the first thing I wanted to do was figure out how to play back our audio quality test files and then do some call audio quality tests.

When doing call audio quality testing, it’s very important that the audio you’re playing back not be transcoded or even resampled, so using PulseAudio or PipeWire was completely out of the question. Figuring this process out turned out to be far harder than I expected, so I thought I should document how I made it work. My background is in IT infrastructure, and I am not an audio engineer or a telephony expert, so I wouldn’t be surprised if there are better ways of doing things. Suggestions are very welcome on Twitter or via email.

How to play audio over a call

1. Insert your SIM into the phone. Then, setup Fedora on a microSD card and boot it
2. Connect to the network either using wifi or a dock
3. Make sure to enable sshd.service if it’s not already enabled. Then SSH into the PinePhone (default username is pine and default password is 123456), and become root (sudo su)
4. Install asterisk dnf -y install asterisk
5. Build and install the Quectel asterisk module. To build the channel module, you’ll need to download the source RPM for the asterisk package installed in step 4, build it (at least to the point where it’s generated the include files), and then pass the build directory to ./configure --with-asterisk=...
6. Copy qeuctel.conf to /etc/asterisk. The defaults should suffice
7. Stop phosh.service and ModemManager.service
8. Setup an extension in /etc/asterisk/extensions.conf with the name [incoming-mobile]. This is what any incoming calls will be directed to. For testing, I suggest renaming the [demo] section to [incoming-mobile]
9. Add the asterisk user to the audio and dialout groups
10. Set the audio mode to Voice call in ALSA by running alsaucm -c PinePhone set _verb 'Voice Call'. (Rather embarrassingly, this step took me days to figure out!)
11. In the playback tab of alsamixer, make sure that Line Out is unmuted (even if the volume is at 0%), along with AIF1 Slot 0 Digital DAC and AIF2 Digital DAC



12. In the recording tab of alsamixer, disable recording for AIF1 Data Digital ADC and AIF2 ADC Mixer ADC. Then, enable recording for AIF2 ADC Mixer AIF1 DA0



13. Start asterisk.service
14. Run asterisk -vvvcgr
15. Call your PinePhone’s number from another phone. On the other phone, you should hear the Asterisk demo (or whatever other audio you configured to play), and on the PinePhone, you should see something like this:



How the PinePhone modem routes audio

(short answer: Magic!)

Figuring out steps 10-12 above was a great example of 10% of the work taking 90% of the time. This section explains what I think is going on here, but a lot of it is guesswork. Unless you’re interested in the inner workings of the PinePhone and its modem, feel free to skip this section.

It didn’t take long for me to figure out how to build asterisk and the Quectel channel module, and, when I placed my first call after starting up asterisk, I was plenty excited when the call went through, Asterisk picked up… and then silence! Roughly 30 seconds of silence (oddly enough, the length of the file I was playing), and then asterisk hung up.

It became clear to me that asterisk thought it was playing audio, even if it wasn’t actually making it to my other phone. Thus started days of experimentation, trying to figure out the problem.

The PinePhone has a Quectel EG25-G LTE modem in it that, by default, provides a number of USB serial devices, one of which (supposedly) is where we’re supposed to send and receive audio.

After loads of scattered documentation around the internet (fun fact, the Quectel EC25 modem has some very different features, so you can’t just assume its manual applies to the EG25-G), it became more and more clear that, for voice calls, the PinePhone’s modem is tied into the PinePhone’s DSP, which is exposed in Linux through ALSA. AIF2 is the modem’s voice channel while AIF1 is the PinePhone’s normal audio DAC.

It took lots of experimentation to work out that, to get audio from the USB serial device to actually get sent through the modem, you need to route AIF1’s output audio into AIF2 (which is what we’re doing in step 12). You also need to enable the AIF1 and AIF2 DACS (step 11), and make sure that Line Out is unmuted.

The strange thing is that, even though we’re using ALSA to enable a number of different switches, none of the volume levels have any effect on the volume sent through the modem. I suspect that this is because Asterisk is already sending the exact audio data without any processing.

One limitation our current system has is that it only transmits audio in 8KHz, which means we haven’t yet been able to test VoLTE. From what I can see, the EG25-G supports VoLTE, but I’ll need to do more research to figure out how to turn it on.

Call quality

So, now that we can play audio through Asterisk, what does the actual call quality look like?

At Spearline, we commonly use PESQ to test a call’s audio quality, and we’ve got a great summary of what PESQ is and what the scores actually mean here. We ran two sets of tests on the PinePhone, one when the phone was in Spearline’s headquarters, and the other when it was in my home (a couple of kilometers away from the office).

This first chart shows the PESQ scores when the phone was at Spearline’s headquarters.

The scores vary from 3.51 to 4.01 with an average of 3.78, which puts them at the top end of the second-highest band of PESQ scores: 3.30-3.79 Attention necessary: no appreciable effort required. In other words, a call placed to the PinePhone while in Spearline’s headquarters would sound good, but you would have to put in a very small amount of effort to pay attention.

This second chart shows the PESQ score when the phone was moved to my home.

Here the scores were higher and more consistent, ranging from 3.88 to 4.02 with an average of 3.96, which puts them in the highest band of PESQ scores: 3.80-4.50 Complete relaxation possible; no effort required. In other words, a call to the PinePhone at my home would result in a call where the conversation could be completely relaxed, with no strain to understand what the other person is saying.

This shows that, as expected, call quality will depend on the tower you’re connected to and the distance to the tower. However, both sets of scores are high enough to make it clear that the PinePhone is fully capable of making high quality audio calls.

Photo Pinephone betaedition by ICCCC used under the CC0 license

At my day job, we’ve just purchased Yubikeys for my team to help in the neverending process of securing our infrastructure.  While we’re looking at implementing MFA in a number of places, the starting point is securing our SSH connections to our servers.  We use FreeIPA to manage authorization and authentication through SSH, so key management is pretty straightforward.   The real question is how best to secure an SSH key using a Yubikey.  There are two main options: setting up a PIV key on the Yubikey or creating an OpenSSH Security Key (SK) key that requires the Yubikey to login.

I tried out the SK key first because the documentation made it look like it was easiest to set up, and (perhaps surprisingly) it was!  Generating the key was a piece of cake.  From a security point of view, I prefer it because the key is stored on my laptop and can be protected with a passphrase.  Theft of the Yubikey alone isn’t enough to compromise the key.  Using the key is simple too. I just need to have my Yubikey plugged into my laptop and tap on it after initiating the SSH session.

The first problem that came up is that our servers run an in-house rpm-ostree distribution based off of AlmaLinux 8, and the latest release of OpenSSH there doesn’t support SK keys.  This problem was easily resolved by taking Fedora’s OpenSSH builds and rebuilding them for our distribution.

The second problem could not be as easily solved, and has, unfortunately, caused me to abandon SK keys.  My team uses Ansible extensively, and we always deploy our changes using our own SSH keys so we can audit who has performed the changes.  Due to the way that Ansible re-uses SSH connections, you only have to tap the Yubikey once when deploying a change to a single server.  However, when deploying a change to many servers (we have over 100 call servers around the world), you have to tap the Yubikey for every. single. server.  This turns a minor speed bump into an insurmountable road block.

This brought me to our second option, PIV keys.  I’d passed them up because setting them up is anything but simple, but most of the pain can be abstracted away, and the extra libraries are only required on the system that has the Yubikey connected. The downside is that PIV keys are stored directly on the Yubikey (as a certificate, if I understand correctly), which means I now need to set a PIN on the Yubikey (otherwise someone can just plug the Yubikey in their computer and use my SSH key) and run extra commands to load the key into my SSH agent every time I insert my Yubikey.  I’m also limited to storing a single SSH key on my Yubikey.

PIV keys are more difficult to setup and maintain than OpenSSH SK keys, but they have one major advantage - Yubikey supports a touch “cache” with PIV authentication.  This means that any SSH connections made within fifteen seconds of a Yubikey touch will be allowed to connect without requiring a second touch.  After configuring Ansible to perform up to 200 simultaneous connections, this reduces a full deployment from 100+ touches to 3, all within the first minute of the deployment.

If we could somehow get either the Yubikey or OpenSSH to support a touch cache for SK keys, I would switch to them in a heartbeat, but, until that feature is added (or we can find a workaround), we’re going to have to stick with PIV authentication.

As always, if you have any suggestions or comments, please either email me or ping me on twitter.
